JK Smart Active Balance BMS 16S 150A (JK-PB1A16S15P)

Description

Cell specifications: 16 Strings Lifepo4/Li-ion/LTOInterface type: Charge and discharge are both at the same port
Work-temperature: -30~70 °C
Storage temperature: -30~70 °C
Work-humidity: 10~80 %RH
Storage humidity: 10~85 %RH
Power Supply: 20~70 V
Working consumption: 19mA@58V

standby consumption: 200uA@58V

With the rapid growth of the renewable energy storage market, there is a growing demand for battery management systems. This product is a smart BMS for energy storage applications. It uses sophisticated detection techniques to achieve protection against overcharging, over discharge, and over current of the energy storage battery, ensuring safe and reliable operation of the energy storage system. At the same time, advanced active voltage equalisation is integrated, allowing the voltage of each battery cell to be monitored in real time, improving battery life through active balance management. This product provides an intelligent battery protection solution for a wide range of energy storage applications.

JK BMS JIKONG Active Balance Smart BMS，Our PB series energy storage Inverter BMS（PB2A16S20P,PB2A16S15P,PB1A16S15P,PB1A16S10P） has been upgraded to the latest V19 version；All orders placed after June 1, 2025 will be set to version V19 by default；

● Number of Battery Strings:7S to 16S.
● Continuous Current:150A.
● Power supply mode:The battery pack is self-powered.
●Single cell voltage detection range:0-5V,error<10mV over full operating range,Typical error value<5mV.
● Support single cell voltage dropout detection.
● Balance current:1000mA,Active Balance(Full State On).
● Wiring method:same port.
● Short Circuit Protection:Support.
● Bluetooth Function:Bluetooth Built-in,Support for Android /IOS Phone.
● Temperature detection:-40～125℃.
● Total voltage detection Detection range:0-100V,<0.5%FSR(FSR=full scale).
●Current Sense Shunt:-150A~300A,Error<0.5%FSR.
●SoC estimation accuracy:Error<8%(operating conditions).
● Battery remaining capacity:error range is less than 8%
● Total Cycle AH Cumulative value is half of the charge/discharge value.
●Operating power consumption:<5mA(without communication)/15mA(485/CAN).
● Standby power consumption:<2mA.
●Operating Temperature:-40~85°C.
● Storing Temperature:-40～95℃.
